TTMOSTM:
| Part Number | BVdss (V) | VGS(V) | VTH(V) | RDS(on)(mΩ)@VGS=10V | Package | |
|---|---|---|---|---|---|---|
| Typ | Typ | Max | ||||
| SRH03P098L | -30 | ±20 | -1 | 8.6 | 9.8 | PDFN3.3*3.3, SOP8 |
| SRH03P142L | ±20 | -1 | 10.9 | 14.2 | ||
| SRT03N010L | 30 | ±20 | 1.5 | 0.8 | 1 | PDFN5*6 PDFN3.3*3.3 TO-252 |
| SRT03N015L* | ±20 | 1.6 | 1.2 | 1.5 | ||
| SRT03N023L | ±20 | 1.7 | 1.7 | 2.3 | ||
| SRT03N023H | ±20 | 3 | 1.83 | 2.3 | ||
| SRH03N058H* | ±20 | 3 | 5 | 5.8 | ||
| SRT04N012L | 40 | ±20 | 1.8 | 1.05 | 1.2 | PDFN5*6 PDFN3.3*3.3 TO-252 |
| SRT04N016L | ±20 | 1.8 | 1.15 | 1.6 | ||
| SRT04N024L | ±20 | 1.8 | 2.1 | 2.4 | ||
| SRT04N037L | ±20 | 1.8 | 3.25 | 3.7 | ||
| SRT06N022H* | 60 | ±20 | 3 | 1.8 | 2.2 | PDFN5*6 SOP8 |
| SRT06N027H* | ±20 | 3 | 2.3 | 2.7 | ||
| SRT06N095L* | ±20 | 1.6 | 8.1 | 9.5 | ||
| SRT08N015H | 80 | ±20 | 3 | 1.3 | 1.5 | TOLL TO-220C, TO-263-2 PDFN5*6 |
| SRT08N025H | ±20 | 3 | 2 | 2.5 | ||
| SRT08N055H* | ±20 | 3 | 4.7 | 5.5 | ||
| SRT10N022H | 100 | ±20 | 3 | 1.5 | 1.9 | TOLL TO-220C, TO-263-2 PDFN5*6 |
| SRT10N042H* | ±20 | 3 | 3.8 | 4.2 | ||
| SRT10N043H | ±20 | 3 | 3.7 | 4.3 | ||
| SRT10N047H | ±20 | 3 | 4.2 | 4.7 | ||
| SRT12N058H | 120 | ±20 | 3 | 5 | 5.8 | PDFN5*6 TO-220C, TO-263-2 |
| SRT12N080H* | ±20 | 3 | 6.8 | 8 | ||
| SRT135N065H* | 135 | ±20 | 3 | 5.6 | 6.5 | PDFN5*6 TO-220C, TO-263-2 |
| SRT135N095H* | ±20 | 3 | 8.1 | 9.5 | ||
| SRT15N050H | 150 | ±20 | 3 | 4 | 5 | PDFN5*6 TO-220C, TO-263-2 |
| SRT15N075H* | ±20 | 3 | 6.4 | 7.5 | ||
| SRT20N090H* | 200 | ±20 | 3 | 6 | 9 | PDFN5*6 TO-220C, TO-263-2 |
| SRT20N135H* | ±20 | 3 | 11.5 | 13.5 | ||
SnowMOSTM:
| Part Number | BVDSS(V) | RDS(on)_MAX(mΩ) | Package | Application |
|---|---|---|---|---|
| SRC65R040B | 650 | 40 | TO-247 | PFC DC/DC |
| SRC65R068B | 68 | |||
| SRC65R072B | 72 | |||
| SRC65R082B | 82 | |||
| SRC60R037B | 600 | 37 | TO-247 | |
| SRC60R068B | 68 | |||
| SRC60R078B | 78 | |||
| SRC60R090B | 90 |
IGBT:
| Part Number | BVCES(V) | IC(A) | Package | Application |
|---|---|---|---|---|
| SRE30N065FSUDF | 650V | 30 | TO-247 | PFC |
| SRE60N065FSUD6 | 650V | 60 | TO-247 | |
| SRE50N065SUS1 | 650V | 50 | TO-247 | |
| SRE40N120FSHD9 | 1200V | 40 | TO-247 | |
| SRE40N120FSHS2 | 1200V | 40A | TO-247 |
SiC MOSFET:
| Part Number | BVDSS(V) | RDS(on)_MAX(mΩ) | Package | Application |
|---|---|---|---|---|
| SRW120R040A* | 1200V | 40 | TO-247 | PFC DC/DC |
| SRW120R080A* | 1200V | 80 | TO-247 |
